Model:MS-ST800
Voltage :100-240v ,50-60Hz
Power consumpption :560W
Light source :144pcs 3w white led,576pcs 0.2W RGB led
Beam angle :RGB:65°White:35°
Channel: 11CH、15CH、59CH、71CH
Lifetime of light source :30000hrs
Strobe:0-20Hz
Dimming :0-100%dimming
Controlled by: DMX512,Master/Slave
Dimensions :530*140*325mm
N.W:12.6kg
IP rating:IP65
EXW:$335-$375
We are a stage lighting factory. Different purchase quantities have different purchase prices. Please feel free to inquire.
Product Description



Technical Parameter
| Optics parameter | |||
| Light source | 144pcs 3w white led,576pcs 0.2W RGB led | ||
| Beam angle | White:35°,RGB:65° | ||
| Illuminance | Distance(m) 1 2 3 | ||
| luminance(lux) R 1000 280 120 | |||
| G 2200 610 260 | |||
| B 510 130 60 | |||
| W 15200 3300 1600 | |||
| Full 19200 4900 2000 | |||
| Lifetime of light source | 30000hrs | ||
| Functions | |||
| Y rotation angle | 270° | ||
| Strobe | 0-20Hz | ||
| Dimming | 0-100% dimming | ||
| Electronic parameter | |||
| Operating voltage | 100-240VAC,50/60Hz | ||
| Power consumption | 560W | ||
| Power connector | Waterproof power input/output connectors | ||
| DMX connector | 3-PIN XLR Waterproof input/output connectors | ||
| Power supply connection | Maximum number of devices in a power supply chain: 2units@100V,4units@240V | ||
| Signal Connection | The maximum number of devices in a DMX chain should not exceed 32 units. | ||
| Ambient temperature | 0℃~40℃ | ||
| Structure specification | |||
| Dimensions | 530*140*325mm | ||
| net weight | 12.6Kg | ||
| IP rating | IP65 | ||
| cooling system | fans cooling | ||
| Installation | standing/hanging | ||
| Control specification | |||
| Channel | 11CH、15CH、59CH、71CH | ||
| Display Elements | 1.8inch TFT display | ||
| Controlled by | DMX512, Master/Slave | ||
